Product Features
- Compact structure, easy to install and use.
- Self-locking pressure adjustment mechanism can prevent pressure changes caused by external interference.
- In addition to the standard type, a low-pressure type is available (maximum adjustable pressure 0.4MPa).
Specifications
Model |
AR1500 |
AR2000 |
BR2000 |
BR3000 |
BR4000 |
Working Medium |
Air |
Port Size [Note 1] |
PT1/8 |
PT1/4 |
PT1/4 |
PT3/8 |
PT1/2 |
Pressure Regulation Range |
0.05–0.9MPa (7–130Psi) |
Max Operating Pressure |
1.0MPa (145Psi) |
Proof Pressure |
1.5MPa (215Psi) |
Operating Temperature Range |
-20–70°C |
Note 1: G and NPT thread types are available.
Product Ordering Code
Position |
Description |
Options & Values |
1 |
Series Code |
- AR: A Series Regulator
- BR: B Series Regulator
|
2 |
Port Size |
- 1500: 1/8"
- 2000: 1/4"
- 3000: 3/8"
- 4000: 1/2"
|
3 |
Model Type Code |
- Blank: Standard Type (0.9MPa)
- L: Low Pressure Type (0.4MPa)
|
4 |
Bracket Code |
- Blank: With Bracket
- J: Without Bracket
|
5 |
Pressure Gauge Code |
- Blank: With Pressure Gauge
- N: Without Pressure Gauge
|
6 |
Pressure Unit |
- 1: MPa
- 2: psi
- 3: bar
- 4: kgf/cm² & psi
|
7 |
Thread Code [Note 1] |
- Blank: PT thread
- G: G thread
- T: NPT thread
|
Note 1: For G and T threads, the pressure gauge dial will display corresponding pressure units.
